Detail Information

Model No.::	RYT-3000	Light Tube Type::	Enclosed X-ray Tube
Maximum Tube Voltage::	90kV	Maximum Tube Current::	0.15mA
Speed::	20 Fps	Resolution::	1176*1104
Size Of Loading::	650mm*550mm（other Sizes Can Be Customized ）
Highlight:	pcb x ray inspection equipment , pcb x ray machine

Product Description

**PCBA PCB X Ray Inspection White Equipment W7 System 20 fps 650mm*550mm**

1.Applications:

1. Semiconductor

2. Electronic Connector Module

3. Automotive electronics

4. Mold Plastic Parts

5. Aircraft Components

6. Electrical and Mechanical Components

7. BGA Inspection

8. PCB,FPC,PCBA

9. Die Castings

10. LED

11. Tyre

2.Specifications:

Function	Advantages
X-ray tube and detector can move along the Z axis	Defects below 2um can be detected
Software sets voltage and current	Convenient maintenance, long service life
It can control the speed of the object carrier in the X-Y direction	Simple operation and short training time for operators
Editable detection program	Suitable for mass detection
The maximum inclination of detector is 45°	Semi-automatic identification of OK/NG products
Large navigation window, click the mouse to move the object table to the point	High repeatability accuracy
	Can accommodate all kinds of large size samples
	Allows a unique view of the sample

3.Numerical Control Programming

1. Create a test program with a simple mouse click

2. The stage can be positioned in the X and Y directions; the X-ray tube and the

detector are positioned in the Z direction.

3. Software sets voltage and current

4. Image settings: brightness, contrast, auto gain and exposure

5. The user can set the pause time of the program switch

6. Anti-collision system can satisfy the maximum tilt and observe objects

7. Automatic analysis of BGA diameter, void ratio, area and roundness

4.Technical Parameters:

Project		Content
Equipment Model No.		RYT-3000
X-RAY transmitting tube (HAMAMATSU,Japan)	Light tube type	Enclosed X-ray tube
	Maximum tube voltage	90kV
	Maximum tube current	0.15mA
	The focal spot size	5um
	Amplification factor	Geometric multiplier: 150 system multiplier: 1000
Detector	Speed	20 fps
	Resolution	1176*1104
	Angle of inclination	±45° incline
Cabinet Specification	Size of loading platform	650mm*550mm(other sizes can be customized )

5.Features:

1, Specific designed to meet differents customers's requirements.
2, 24 hours technical support by email and telephone service..
3, Warranty: 1year for free repair (Except consumables), provide free technical service support for all life.
4, Provide English manual or operating video.
